  AG2.0B Type Ultrasonic Evaporation Transducer
 Product Category:Meteorological Instrument
 Product Code:AG2.0B
 Entering Time:2017/3/22
 Clicks: 13169
Enlarge Image
Product INformation:

AG2.0B Type Ultrasonic Evaporation Transducer

AG2.0B Type Ultrasonic Evaporation Transducer is based on the principle of ultrasonic ranging, by selecting high-precision ultrasonic sensor, the distance of sensor to water surface will be accurately measured and converted into electrical signals output, the water capacity evaporated will be immediately measured out.  The transducer will are used with Model E-601B evaporation barrels, hydrosphere and instrument shelter.

AG2.0B Type Ultrasonic Evaporation Transducer is designed on the base of  AG1.0 Type, it improved measurement environment and raised measurement accuracy.  The transducer is used in meteorological, hydrographic departments of measuring the water and evaporation capacity.

Technical parameters

Measuring range

0mm100mm

Resolution

0.15%

linear

±0.5%

Max. permissible errors

±1.5%F.S.working temperature: 050

Power supply

10 V15V DC

Output

4mA20mAload resistance: 500Ω

Working temperature

050

High water graduation output

4mA

Low water   graduation output

20mA

Cable length

2m

Dimension

φ200mm×340mm

Weight

3.4kg
