 Pressure Transmitter
  K-GPB Rod-type Series Pressure Transmitter
 Product Category:Pressure Transmitter
 Product Code:
 Entering Time:2010/4/19
 Clicks: 12946
Enlarge Image
Product INformation:

The products are selected high-quality, world-famous brand diffused silicon, ceramic piezoresistive and sapphire as a measuring element. Based on the traditional rod-type pressure transmitters, it is added intelligent HART5 communication function.

It is characteristic of high precision, small size, light weight, easy installation, long-term stable and high reliable.

Accuracy:0.5%0.25%0.1%

Measurement range:

KGPB:0-3.5kPa35MPa

KGPT:0.35200m(input type)

K-GPBC0-40kPa60MPa

K-GP Series Transmitters

Product parameters:

Measurement rang(kPa):060000

Output:420mA DC

Accuracy: ±0.5%±0.25%±0.1%

Power supply voltage: 24V DC

Installation in dangerous places: Exd CT5   Exia CT5

Application:

It is equipped with computers, recorders, alarms, regulator and counters to measure the process fluid pressure, absolute pressure, and the liquid level of opening container, pool, and river, resulting to realize automatic detection and control of production process.
